Bilstein Shock Absorbers
        Bilstein

        Bilstein Shock Absorbers

        Part Number:25-101874
        Bilstein B8 5150 fixed reservoir shock absorbers combine our high gas pressure monotube shocks with a race-inspired, fixed CrossFlow reservoir. Designed specifically for lifted and custom applications, the adjustable shock mount allows unlimited reservoir positioning. The 46mm digressive piston is available in a variety of valvings for single or multiple shock applications. The Bilstein B8 5150 shock absorber features a steel body with a platinum powder coated finish.
        • Race inspired fixed CrossFlow reservoir
        • Adjustable shock mount allows unlimited reservoir positioning
        • Advanced design splut valving
        Retail price
        • $1.00
        Features
        • SKU
          25-101874
        • Brand
          Bilstein
        • Body Design
          Smooth Body
        • Body Diameter
          46mm ID
        • Coilover Type
          Non-Coilover
        • Collapsed Length
          17.78 in.
        • Collapsed Length
          451.5 mm
        • Compression at 0.52 m/s
          740.0 N
        • Extended Length
          29.7 in.
        • Extended Length
          754.5 mm
        • Finish
          Platinum Powder coat
        • Includes Boot
          No
        • Includes Reservoir
          Yes
        • Includes Spring Seat
          No
        • Internal Design
          Monotube
        • Lower Mount Type
          Eye 15.875 mm
        • PartType
          Shocks / Struts
        • Prop 65 (Y/N)
          Y
        • Prop 65 - Short Label
          WARNING: Cancer & Reproductive Harm - www.P65Warnings.ca.gov
        • Rebound @0.52m/s
          2665
        • Segment
          Light Truck
        • Series
          B8 5150
        • Spring Max Travel (IN)
          11.92
        • Title
          Bilstein Shock Absorbers
        • Upper Mount Type
          Eye 15.875 mm
