Bilstein

Bilstein Shock Absorbers

Part Number:25-101966
Discontinued
Bilstein B8 5150 fixed reservoir shock absorbers combine our high gas pressure monotube shocks with a race-inspired, fixed CrossFlow reservoir. Designed specifically for lifted and custom applications, the adjustable shock mount allows unlimited reservoir positioning. The 46mm digressive piston is available in a variety of valvings for single or multiple shock applications. The Bilstein B8 5150 shock absorber features a steel body with a platinum powder coated finish.
  • Race inspired fixed CrossFlow reservoir
  • Adjustable shock mount allows unlimited reservoir positioning
  • Advanced design splut valving
Retail price
  • $1.00
Features
  • SKU
    25-101966
  • Brand
    Bilstein
  • Body Design
    Smooth Body
  • Body Diameter
    46mm ID
  • Coilover Type
    Non-Coilover
  • Collapsed Length
    15.89 in.
  • Collapsed Length
    403.5 mm
  • Compression at 0.52 m/s
    575.0 N
  • Extended Length
    25.91 in.
  • Extended Length
    658.0 mm
  • Finish
    Platinum Powder coat
  • Includes Boot
    No
  • Includes Reservoir
    Yes
  • Includes Spring Seat
    No
  • Internal Design
    Monotube
  • Lower Mount Type
    Eye 15.875 mm
  • Rebound @0.52m/s
    1600
  • Series
    B8 5150
  • Upper Mount Type
    Eye 15.875 mm
See More
