Bilstein Shock Absorbers
Bilstein

Bilstein Shock Absorbers

Part Number:33-225630
Bilstein B8 8125 coilovers are engineered for the serious off-road enthusiast, available in both 46mm (2 inch) and 60mm (2.65 inch) sizes. Designed for use with dual-rate springs and available in a wide range of travel lengths, these performance coilovers are perfect for custom coilover suspension applications. Equipped with a competition designed, 3-stage seal pack, these coilovers withstand the harshest off-road environments. All B8 8125 coilovers include a 22mm hard chromed, case hardened piston rod which provides exceptional tensile strength and resistance to sand blasting and rock chipping. Incorporated remote reservoir combined with a high-temp hose provides consistent fade free performance under conditions of intense heat. The zinc coated threaded body allows for quick ride height adjustments and spring changes. Bilstein B8 8125 coilovers are completely owner rebuildable with replacement parts available from Bilstein. All components are machined to precise tolerances and made in the USA to insure high quality.
  • Available in 46mm and 60mm monotubes for consistent, fade-free performance
  • Threaded body with dual-rate coilover hardware
  • Remote reservoir for greater resistance to heat and increased travel length
Retail price
  • $604.00
Features
  • SKU
    33-225630
  • Brand
    Bilstein
  • Body Design
    Threaded Body
  • Body Inside Diameter
    60.0 mm
  • Coilover Type
    Coilover
  • Collapsed Length
    24.5 in.
  • Collapsed Length
    25.0 in.
  • Collapsed Length
    622.3 mm
  • Compression at 0.52 m/s
    1,100.0 N
  • Extended Length
    38.5 in.
  • Extended Length
    39.0 in.
  • Extended Length
    977.9 mm
  • Finish
    Zinc Plated
  • Includes Reservoir
    Yes
  • Includes Spring Seat
    Yes
  • Internal Design
    Monotube
  • Lower Mount Type
    Eye 12.7 x 38.1 mm
  • Mount End Type
    Eye-To-Eye
  • Rebound @0.52m/s
    3700
  • Recommended Additional Part
    Reservoir Clamp: B4-KT1-Z292A00
  • Series
    B8 8125
  • Shock Cap Type
    Screw Top
  • Upper Mount Type
    Eye 12.7 x 38.1 mm
