Bilstein Shock Absorbers
        Bilstein

        Bilstein Shock Absorbers

        Part Number:33-247830
        Bilstein AS2 Series shock absorbers are designed for motorsports applications and provide the user with the option to rebuild them. The modular aluminum design is offered in non-, single and double adjustable configurations which provide superior on-vehicle tuning capabilities. The threaded body provides precise height adjustments for coilover setups and dissipates heat quickly. The hard anodized coating reduces internal friction and improves strength and durability (pistons, piston bands and heims are sold separately to allow for a variety of combinations). AS2 Series shock absorbers are ideal for racers demanding a lightweight design with upgrade capability.
        • 46mm lightweight extruded aluminum body for superior heat dissipation
        • Fine thread body provides precise adjustments in coilover applications
        • Single and double adjustable shaft options available
        Retail price
        • $259.00
        Features
        • SKU
          33-247830
        • Brand
          Bilstein
        • Adjustable Damping
          No
        • Body Design
          Threaded Body
        • Body Inside Diameter
          46.0 mm
        • Body Material
          Aluminum
        • Coilover Type
          Coilover
        • Collapsed Length
          15.12 in.
        • Collapsed Length
          384.0 mm
        • Color
          Natural
        • Extended Length
          23.98 in.
        • Extended Length
          609.0 mm
        • Finish
          Anodized
        • Includes Boot
          No
        • Includes Spring Seat
          No
        • Internal Design
          Monotube
        • Lower Mount Type
          12.7 mm Heim
        • PartType
          Shocks / Struts
        • Piston Style
          Digressive
        • Prop 65 (Y/N)
          Y
        • Prop 65 - Short Label
          WARNING: Cancer & Reproductive Harm - www.P65Warnings.ca.gov
        • Segment
          Motorsports
        • Series
          AS2 Series
        • Shock Cap Type
          Screw Top
        • Spring Hardware
          B4-KT1-Z245A01
        • Spring Max Travel (IN)
          8.86
        • Title
          Bilstein Shock Absorbers
        • Upper Mount Type
          12.7 mm Heim
        • Valve Type
          Digressive Dry Kit (no valving)
