HEDMAN HEDDERS CHEVY PU SMALL BLOCK 55-65- BLACK MAXX
        Hedman Hedders

        HEDMAN HEDDERS CHEVY PU SMALL BLOCK 55-65- BLACK MAXX

        Part Number:69263

        Hedman Hedders has been manufacturing quality headers in the USA since 1954, and they've been manufacturing long and mid-length tube headers for Chevy trucks for nearly as long. Each set uses mild steel, smooth flowing, CNC mandrel bent tubes, that are hand-welded to ensure each pair is identical to the next. Hedman's unique, gasketless ball and socket collector design allows your Small Block Chevy exhaust system to bolt up, even if it is not perfectly aligned with the header collectors.

        These BLACK-MAXX coated, LONG-TUBE headers fit 1955-1966 2WD (only) 1/2 and 3/4 ton Chevy Trucks wish a Small Block Chevy powerplant (check the application listings for exact fitment). The smooth 1-1/2 in. tube design provides ample exhaust flow to let your classic truck's 283-400 SB Chevy engine breathe easy, and produce maximum horsepower and torque.

        Each set includes a pair of gaskets, header flange bolts and collector bolts. No collector gasket is needed.

        Hedman Hedders is so confident in the quality of its headers that these headers are factory backed by a Limited Lifetime Warranty. These headers have a high temperature, SATIN-BLACK ceramic finish that resists corrosion, and can withstand temperatures up to 1400 degree F. This finish is covered by a 5-year factory warranty, in addition to Hedman's standard lifetime header warranty.

        • Handcrafted, Mild Steel Construction.
        • Long Tube Header Design Provides Excellent Top-End Horsepower and Torque.
        • Ball & Socket Collector Design requires No Gasket, and Allows For More Exhaust System Misalignment than Old School, Gasket-Style Header Collectors
        • Includes All The Necessary Mounting Hardware, Gaskets and Reducers (exhaust adapters)
        • Limted Lifetime Warranty On Construction, Five Year Warranty on Factory-Applied Header Coating!
        • Proud To Say, Made In The USA, Since 1954!
        Retail price
        • $1,356.21
        Features
        • SKU
          69263
        • Brand
          Hedman Hedders
        • 50-State Street Legal
          Please Refer to Vehicle Fitment Data for CARB EO Information
        • Air Conditioning
          Yes
        • Alternate Variation Part Number
          69260, 69268
        • Automatic Transmission - Column
          Yes
        • Automatic Transmission - Floor
          Yes
        • California Restricted
          Legal on 1974 and Earlier Vehicles When Existing Emission Controls are Retained.
        • Collector Diameter
          3.0 in.
        • Collector Style
          Ball and Socket (Gasketless)
        • Color
          Black Maxx
        • Cylinder Head Port Shape
          Round
        • Exhaust System Diameter
          2.5 in.
        • Finish
          Satin Ceramic-Metallic
        • Fitment Note
          Fits 2WD
        • Fitment Note
          Fits Factory GM Aluminum Angle Plug and Straight Plug Heads.
        • Flange Style
          Standard
        • Flange Thickness
          0.3125 in.
        • Header Style
          Long Tubes
        • Includes Bolts/Studs
          Yes
        • Includes Catalytic Converters
          No
        • Includes Collector Bolts
          Yes
        • Includes Crossover Pipe
          No
        • Includes Gasket/Seal
          Yes
        • Includes Header Fasteners
          Yes
        • Includes Motor Mounts
          No
        • Includes Mounting Hardware
          Yes
        • Includes Reducers
          Yes
        • Includes Y-Pipe
          No
        • Installation Note
          Will Not Fit Torsion Bar Suspension.
        • Manual Transmission - Column
          No
        • Manual Transmission - Floor
          Yes
        • Material
          Mild Steel
        • Material
          Standard-Duty Mild Steel
        • Package Contents
          Headers, Ball and Socket Reducers (Exhaust Adapters), Gaskets, Mounting Hardware
        • Package Contents
          Headers, Collector Flange Gaskets, Collector Bolts.
        • Primary Tube Diameter
          1.50 in.
        • Prop 65 - Short Label
          WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov
        • Reducer Outlet Size
          2.5 in.
        • Replacement Head Flange Gasket Part Number
          27500
        • Replacement Manifold Gasket Part Number
          27500
        • Sold As
          Pair
        • Title
          HEDMAN HEDDERS CHEVY PU SMALL BLOCK 55-65- BLACK MAXX
        • Tube Design
          Standard
        • Tube Diameter
          1.5 in.
        • Tube Size
          1.5 in.
        • Tube Thickness
          16 ga
        • Tuned
          No
        • Weld-Up
          No
        • With A.I.R. System
          No
        • With EGR
          No
        • With Power Steering
          Yes
