ICON 2005-2023 Toyota Tacoma, 6” Lift, Rear, 2.5 VS Remote Reservoir Shocks, Pair
ICON Vehicle Dynamics

ICON 2005-2023 Toyota Tacoma, 6” Lift, Rear, 2.5 VS Remote Reservoir Shocks, Pair

Part Number:57806P
ICON Vehicle Specific (V.S.) 2.5 Aluminum Series shocks are designed and built to give your vehicle outstanding performance off-road and a smooth ride on the street. These shocks are configured specifically for each application in both length and damping tune. Like all ICON'S Shock Absorbers, V.S. 2.5 Aluminum Series shocks are 100% rebuildable and 100% revalveable. For piggyback and specific remote reservoir applications, ICON'S unique use of a 6061 billet aluminum manifold a few inches below the top cap of the shock creates an internal Bump Zone that when used creates an additional 20% of damping force. This additional force helps prevent harsh bottom outs and controls the suspension when compressing at high velocity. If you are looking for a more user defined tune, consider looking into the Compression Damping Control Valve (CDCV) shocks.
  • One-piece impact extruded aluminum cylinders offer excellent corrosion resistance and consistent finish
  • Nitrogen charged monotube design with piggyback reservoir
  • 100% Rebuildable
  • 100% Revalveable
  • ICON’s internal “Bump Zone” increases damping by 20% to provide more control as the shock approaches full compression
  • One piece digressive piston design with vehicle specific valving for unsurpassed performance and ride quality on and off-road
  • Remote reservoir design improves heat dissipation to reduce shock fade during prolonged use
  • 7/8” diameter induction hardened, chrome plated shock shafts
  • PTFE lined spherical bearings and application specific mounting hardware
  • Premium grade 5WT shock oil for consistent suspension damping along a wide temperature range
  • 6061 aircraft grade aluminum CNC machined components
  • All ICON 2.5 Series Piggyback and Remote Reservoir shocks can be upgraded to ICON’s Compression Damping Control Valve (CDCV)
Retail price
  • $1,253.17
Features
  • SKU
    57806P
  • Brand
    ICON Vehicle Dynamics
  • Adjustable Damping
    No
  • Bore Diameter
    57.15.0 mm
  • Cylinder Diameter
    2.5 in.
  • Damping Type
    Oil
  • External Reservoir
    Yes
  • Gas Charged
    Yes
  • Grade Type
    Performance
  • Includes Boot
    No
  • Includes Mounting Hardware
    Yes
  • Lower Mount Type
    Eyelet
  • Mount Type - Upper
    Stem
  • Prop 65 - Short Label
    WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov
  • Recommended Additional Part
    191016 - 7.5 in. Finned Reservoir Upgrade Kit
  • Recommended Additional Part
    252001 - 2.5 Fixed Spanner Wrench
  • Recommended Additional Part
    252002 - Universal Spanner Wrench (2.0/2.5/3.0)
  • Recommended Additional Part
    252003 - Seal Install Tool 2.5/3.0
  • Recommended Additional Part
    252011 - 2.5 Piggyback/remote Reservoir/bypass Rebuild Kit
  • Recommended Additional Part
    252012 - -4 TO -10 HOSE SHIELD KIT
  • Recommended Additional Part
    254100G - 1.0 Gallon Icon Performance Shock Oil
  • Recommended Additional Part
    257340 - 0.875 in. Shaft 14.25 Overall Length, 10.0 Travel
  • Recommended Additional Part
    611007 - 0.563 in. Medium Duty Stem Bushing Kit
  • Shaft Diameter
    0.875 in.
  • Shock Absorber Body End Measuring Point
    Shoulder of Stem
  • Shock Absorber Rod End Measuring Point
    Center of Eyelet
  • Tube Outside Diameter
    2.5 in.
