ICON 2000-2006 Toyota Tundra/2001-2007 Toyota Sequoia, V.S. 2.5 Series Coilover Kit, Internal Reservoir
ICON Vehicle Dynamics

ICON 2000-2006 Toyota Tundra/2001-2007 Toyota Sequoia, V.S. 2.5 Series Coilover Kit, Internal Reservoir

Part Number:58620
ICON Vehicle Dynamics V.S. 2.5 Series internal reservoir front coilover shocks are an incredible upgrade for the front end of the 2000-2006 Toyota Tundra and 2001-2007 Toyota Sequoia. These adjustable coilovers allow up 0-2.5” of lift height adjustability, allowing the use of larger, more aggressive wheel and tire combinations. ICON’s Vehicle-specific shock length and valving, their large 2.5” shock body with increased piston surface area over stock components, yield increased front wheel travel along with superior ride quality and suspension performance both on- and off-road. When paired with ICON 2.0 or 2.5 Aluminum Series rear shock absorbers vehicle control will be balanced front to rear, resulting in the best overall driving experience for your vehicle.
  • Vehicle specific tuned for superior shock damping, vehicle control, and improved ride quality over stock
  • Vehicle specific shock length and pairing with stock front upper control arms yield increased wheel travel
  • Height-adjustable coilovers offer 0-2.5" of lift height adjustment over stock
  • 2.5" diameter shock bodies with internal reservoirs for consistent performance
  • ICON engineered coil springs
  • 6061 Aircraft grade aluminum CNC machined components
  • Corrosion resistant CAD plated shock bodies with 7/8" diameter shafts
  • FK rod end bearings for extended longevity and minimal deflection
  • Fully rebuildable and re-tunable
Retail price
  • $1,594.27
Features
  • SKU
    58620
  • Brand
    ICON Vehicle Dynamics
  • Adjustable Damping
    No
  • Adjustable Height
    Yes
  • Body Diameter
    2.5 in.
  • Damping Type
    Oil
  • Fitment Note
    Does fit OEM Wheels and Tires
  • Gas Charged
    Yes
  • Grade Type
    Performance
  • Includes Boot
    No
  • Material
    Aluminum
  • Maximum Lift
    3.0 in.
  • Minimum Lift
    0
  • Mount Type - Lower
    Eyelet
  • Mount Type - Upper
    Mounting Plate
  • Prop 65 - Short Label
    WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov
  • Recommended Additional Part
    191003 - ICON SHORT 2.5 COIL WRAP W/LOGO PAIR (11.25-12.25)
  • Recommended Additional Part
    198000 - 2 PIN COILOVER SPANNER WRENCH KIT
  • Recommended Additional Part
    198001 - BILLET SPANNER WRENCH KIT
  • Recommended Additional Part
    252001 - 2.5 Fixed Spanner Wrench
  • Recommended Additional Part
    252002 - Universal Spanner Wrench (2.0/2.5/3.0)
  • Recommended Additional Part
    252003 - Seal Install Tool 2.5/3.0
  • Recommended Additional Part
    252004 - Economy Needle Charging Tool
  • Recommended Additional Part
    252010 - 2.5 Ifp Rebuild Kit
  • Recommended Additional Part
    254100G - 1.0 Gallon Icon Performance Shock Oil
  • Recommended Additional Part
    611019 - Coilover Hardware Kit Pair
  • Recommended Aftermarket Tires
    33.0 in. X 11.5 in. (Larger Tires may Fit but Fender Trimming and Modifications will be Required)
  • Remote Reservoir
    No
  • Shaft Diameter
    0.875 in.
  • Shock Absorber Body End Measuring Point
    Top of Upper Mount Plate
  • Shock Absorber Rod End Measuring Point
    Center of Eyelet
  • Spring Color
    Black
  • Spring Material
    Steel
  • Spring Rate Type
    Linear
