ICON 2010-2024 Toyota 4Runner/2010-2014 FJ Cruiser/2010-2023 Lexus GX460, 0-3.5" Lift, V.S. 2.5 Series Coilover Kit, Internal Reservoir
ICON Vehicle Dynamics

ICON 2010-2024 Toyota 4Runner/2010-2014 FJ Cruiser/2010-2023 Lexus GX460, 0-3.5" Lift, V.S. 2.5 Series Coilover Kit, Internal Reservoir

Part Number:58646
ICON Vehicle Dynamics V.S. 2.5 Series internal reservoir front coilover shocks are an incredible upgrade for the front end of the 2010-2024 Toyota 4Runner, 2010-2014 Toyota FJ Cruiser, and 2010-2023 Lexus GX460. These adjustable coilovers allow up to 0-3.5” of lift height adjustability, allowing the use of larger, more aggressive wheel and tire combinations. ICON’s Vehicle-specific shock length and valving along with the larger 2.5” shock body and increased piston area over stock components yield the maximum travel possible, while still being compatible with the vehicle’s stock front upper control arms, along with superior ride quality and suspension performance both on- and off-road. When paired with ICON 2.0 or 2.5 Aluminum Series rear shock absorbers vehicle control will be balanced front to rear, resulting in the best overall driving experience for your Toyota 4Runner, FJ Cruiser or Lexus GX460.
  • Adjustable coilovers yield 0-3.5" of front lift height
  • Increased wheel travel and vehicle specific valving provides unrivaled ride quality across a wide range of on and off-road use
  • Superior low speed control reduces body roll and increases on-road stability
  • High quality ICON-engineered coil springs are guaranteed for life against sagging or breakage
  • Corrosion resistant CAD plated shock body with 7/8" shaft
  • FK Rod End bearings provide extended longevity and minimal deflection
  • Fully serviceable design allows for revalves, rebuilds, and an immeasurable service life
  • Bolt-in design makes for an easy install into OEM shock location
Retail price
  • $1,594.27
Features
  • SKU
    58646
  • Brand
    ICON Vehicle Dynamics
  • Adjustable Damping
    No
  • Adjustable Height
    Yes
  • Body Diameter
    2.5 in.
  • Damping Type
    Oil
  • Fitment Note
    Does fit OEM Wheels and Tires
  • Gas Charged
    Yes
  • Grade Type
    Performance
  • Includes Boot
    No
  • Material
    Aluminum
  • Maximum Lift
    3.5 in.
  • Mount Type - Lower
    Eyelet
  • Mount Type - Upper
    Mounting Plate
  • Prop 65 - Short Label
    WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov
  • Recommended Additional Part
    191003 - ICON SHORT 2.5 COIL WRAP W/LOGO PAIR (11.25-12.25)
  • Recommended Additional Part
    198000 - 2 PIN COILOVER SPANNER WRENCH KIT
  • Recommended Additional Part
    198001 - BILLET SPANNER WRENCH KIT
  • Recommended Additional Part
    252001 - 2.5 Fixed Spanner Wrench
  • Recommended Additional Part
    252002 - Universal Spanner Wrench (2.0/2.5/3.0)
  • Recommended Additional Part
    252003 - Seal Install Tool 2.5/3.0
  • Recommended Additional Part
    252004 - Economy Needle Charging Tool
  • Recommended Additional Part
    252010 - 2.5 Ifp Rebuild Kit
  • Recommended Additional Part
    254100G - 1.0 Gallon Icon Performance Shock Oil
  • Recommended Additional Part
    611019 - Coilover Hardware Kit Pair
  • Recommended Aftermarket Tires
    33.0 in. X 11.5 in. (Larger Tires may Fit but Fender Trimming and Modifications will be Required)
  • Remote Reservoir
    No
  • Shaft Diameter
    0.875 in.
  • Shock Absorber Body End Measuring Point
    Top of Upper Mount Plate
  • Shock Absorber Rod End Measuring Point
    Center of Eyelet
  • Spring Color
    Black
  • Spring Material
    Steel
  • Spring Rate Type
    Linear
