ICON 19-23 GM 1500, 0-3.5” Lift, Front, 2.5 VS Ext Travel RR/CDCV Coilover Kit
ICON Vehicle Dynamics

ICON 19-23 GM 1500, 0-3.5” Lift, Front, 2.5 VS Ext Travel RR/CDCV Coilover Kit

Part Number:71656C

2019-UP GM 1500 EXTENDED TRAVEL 2.5 VS REMOTE RESERVOIR CDCV COILOVER KIT

The ICON Vehicle Dynamics V.S. 2.5 Series remote reservoir coilover shocks are an incredible upgrade for the front end of the 2019-2023 GM Silverado/Sierra 1500. ICON’s Vehicle-specific valving provides a sport tuned feel on and off-road while offering 1.5-3.5” of lift height adjustability for use of larger, more aggressive wheel and tire combinations. ICON's larger 2.5” shock body and increased piston area over stock components provides improved damping ability and outstanding ride characteristics across varying types of terrain. Remote reservoirs ensure optimum performance by increasing the duration of consistent damping regardless of situation, keeping the shocks at a cooler operating temperature during heavy use. The ICON CDC Valve upgrade is included for those desiring an easy way to tune the ride externally with 10 adjustment settings from soft to hard. When paired with ICON 2.0 Aluminum Series or 2.5 Series rear shocks, vehicle control will be balanced front to rear resulting in the best overall driving experience for your GM truck.
  • Increased wheel travel and ride quality over stock
  • 100% Bolt-on - no drilling or welding necessary for installation
  • Vehicle specific tuned for superior shock damping and control
  • External reservoir to attain cooler operating temperatures during extended offroad use
  • ICON CDCV equipped for external tunability of your shocks
  • Height-adjustable coilovers offer 1.5-3.5" of front lift height
  • ICON engineered Eibach coil springs
  • 6061 aircraft grade aluminum CNC machined components
  • Corrosion resistant CAD plated shock body with 7/8" shaft
  • FK Rod End bearings for extended longevity and minimal deflection

Retail price
  • $2,719.03
Features
  • SKU
    71656C
  • Brand
    ICON Vehicle Dynamics
  • Adjustable Damping
    Yes
  • Adjustable Height
    Yes
  • Body Diameter
    2.5 in.
  • Damping Type
    Oil
  • Fitment Note
    Does fit OEM Wheels and Tires
  • Gas Charged
    Yes
  • Grade Type
    Performance
  • Housing Material
    Steel
  • Includes Boot
    No
  • Material
    Aluminum
  • Mount Type - Lower
    Eyelet
  • Mount Type - Upper
    Mounting Plate
  • Prop 65 - Short Label
    WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov
  • Recommended Additional Part
    191003 - ICON SHORT 2.5 COIL WRAP W/LOGO PAIR (11.25-12.25)
  • Recommended Additional Part
    191016 - 7.5 in. Finned Resi Upgrade Kit
  • Recommended Additional Part
    198000 - 2 PIN COILOVER SPANNER WRENCH KIT
  • Recommended Additional Part
    198001 - BILLET SPANNER WRENCH KIT
  • Recommended Additional Part
    252001 - 2.5 Fixed Spanner Wrench
  • Recommended Additional Part
    252002 - Universal Spanner Wrench (2.0/2.5/3.0)
  • Recommended Additional Part
    252003 - Seal Install Tool 2.5/3.0
  • Recommended Additional Part
    252011 - 2.5 Piggyback/remote Resi/bypass Rebuild Kit
  • Recommended Additional Part
    252012 - -4 TO -10 HOSE SHIELD KIT
  • Recommended Additional Part
    254100G - 1.0 Gallon Icon Performance Shock Oil
  • Recommended Additional Part
    611019 - Coilover Hardware Kit Pair
  • Remote Reservoir
    Yes
  • Shaft Diameter
    0.875 in.
  • Shock Absorber Body End Measuring Point
    Top of Upper Mount Plate
  • Shock Absorber Rod End Measuring Point
    Center of Eyelet
  • Spring Color
    Black
  • Spring Material
    Steel
