ICON 2019-2023 Ford Ranger, Extended Travel 2.5 VS Remote Reservoir Coilover Kit
        ICON Vehicle Dynamics

        ICON 2019-2023 Ford Ranger, Extended Travel 2.5 VS Remote Reservoir Coilover Kit

        Part Number:91355
        ICON Vehicle Dynamics V.S. Series 2.5” remote reservoir coilover shocks are an incredible upgrade for the front end of the 2019-2023 Ford Ranger. ICON’s Vehicle-specific valving provides a sport tuned feel on and off-road while offering 0-3.5” of lift height adjustability for use of larger, more aggressive wheel and tire combinations. The larger 2.5” shock body and increased piston area over stock components provides improved damping ability and outstanding ride characteristics across varying types of terrain. Remote reservoirs ensure optimum performance by increasing the duration of consistent damping regardless of situation, keeping the shocks at a cooler operating temperature during heavy use. When paired with ICON rear 2.0 Aluminum Series or 2.5" Series shocks, vehicle control will be balanced front to rear resulting in the best overall driving experience for your Ranger.
        • Increased wheel travel over stock
        • FK Rod End bearings for extended longevity and minimal deflection
        • 100% Bolt-on - no cutting or welding necessary for installation
        • Vehicle specific tuned front shocks for superior shock damping and control
        • External reservoir to attain cooler operating temperatures during extended off-road use
        • Improved ride quality over stock both on and off-road
        • Height-adjustable coilovers offer 0-3.5” of lift height adjustment
        • ICON engineered coil springs
        • 6061 Aircraft grade aluminum CNC machined components
        • Corrosion resistant CAD plated shock body with 7/8" induction hardened, chrome plated shaft
        • High strength alloy CNC machined lower bar pin
        Retail price
        • $2,074.75
        Features
        • SKU
          91355
        • Brand
          ICON Vehicle Dynamics
        • AAP_UDA_12
          EA
        • AAP_UDA_22
          1
        • AAP_UDA_4
          55
        • Adjustable Damping
          No
        • Adjustable Height
          Yes
        • Body Diameter
          2.5 in.
        • California Prop 65 Warning
          Yes
        • Damping Type
          Oil
        • Fitment Note
          Does fit OEM Wheels and Tires
        • Gas Charged
          Yes
        • Grade Type
          Performance
        • Housing Material
          Steel
        • Material
          Aluminum
        • Maximum Lift
          3.5 in.
        • Minimum Lift
          0
        • Mount Type - Lower
          Bar Pin
        • Mount Type - Upper
          Mounting Plate
        • Prop 65 - Short Label
          WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov
        • Recommended Additional Part
          191003 - ICON SHORT 2.5 COIL WRAP W/LOGO PAIR (11.25-12.25)
        • Recommended Additional Part
          191016 - 7.5 in. Finned Resi Upgrade Kit
        • Recommended Additional Part
          198000 - 2 PIN COILOVER SPANNER WRENCH KIT
        • Recommended Additional Part
          198001 - BILLET SPANNER WRENCH KIT
        • Recommended Additional Part
          252001 - 2.5 Fixed Spanner Wrench
        • Recommended Additional Part
          252002 - Universal Spanner Wrench (2.0/2.5/3.0)
        • Recommended Additional Part
          252003 - Seal Install Tool 2.5/3.0
        • Recommended Additional Part
          252011 - 2.5 Piggyback/remote Resi/bypass Rebuild Kit
        • Recommended Additional Part
          252012 - -4 TO -10 HOSE SHIELD KIT
        • Recommended Additional Part
          254100G - 1.0 Gallon Icon Performance Shock Oil
        • Recommended Additional Part
          611019 - Coilover Hardware Kit Pair
        • Recommended Aftermarket Tires
          33.0 in.x11.25 in. (Larger Tires may Fit but Fender Trimming and Modifications will be Required)
        • Recommended Aftermarket Wheels
          ICON Alloys - 17x8.5 w/ 5.75" Backspace / 25mm Offset
        • Recommended Aftermarket Wheels
          ICON Alloys - 18x9" w/ 6.00” Backspace / 25mm Offset
        • Remote Reservoir
          Yes
        • Shaft Diameter
          0.875 in.
        • Shock Absorber Body End Measuring Point
          Top of Upper Mount Plate
        • Shock Absorber Rod End Measuring Point
          Flat on Bar Pin
        • Spring Color
          Black
        • Spring Material
          Steel
        • Spring Rate Type
          Linear
