2014 F150 2WD 0-2.63" 2.5 VS IR COILOVER KIT
        ICON Vehicle Dynamics

        2014 F150 2WD 0-2.63" 2.5 VS IR COILOVER KIT

        Part Number:91615
        ICON Vehicle Dynamics V.S. Series 2.5” coilover shocks are an incredible upgrade for the front end of 2014 F150 2WD trucks. ICON’s Vehicle-specific valving provides a sport tuned feel on and off-road while 0-2.63” of lift height adjustability allows the use of larger, more aggressive wheel and tire combinations. The larger 2.5” shock body and increased piston area over stock components provides improved damping ability and outstanding ride characteristics across varying types of terrain. When paired with ICON rear 2.0 Aluminum Series or 2.5 Series shocks, vehicle control will be balanced front to rear resulting in the best overall driving experience for your F150 truck.
        • Increase in wheel travel over stock
        • 100% Bolt-on - no drilling or welding necessary for installation
        • Vehicle specific tuned front shocks for superior shock damping and control
        • Improved ride quality over stock both on and off-road
        • Height-adjustable coilovers offer 0-2.63" of lift height adjustment
        • ICON engineered coil springs
        • 6061 aircraft grade aluminum CNC machined components
        • Corrosion resistant CAD plated shock bodies with 7/8" induction hardened, chrome plated shafts
        • High strength alloy CNC machined lower bar pin
        • FK Rod End bearings for extended longevity and minimal deflection
        Retail price
        • $1,910.95
        Features
        • SKU
          91615
        • Brand
          ICON Vehicle Dynamics
        • AAP_UDA_12
          EA
        • AAP_UDA_22
          1
        • AAP_UDA_4
          55
        • Adjustable Damping
          No
        • Adjustable Height
          Yes
        • Body Diameter
          2.5 in.
        • California Prop 65 Warning
          Yes
        • Damping Type
          Oil
        • Fitment Note
          Does fit OEM Wheels and Tires
        • Gas Charged
          Yes
        • Grade Type
          Performance
        • Includes Boot
          No
        • Mount Type - Lower
          Bar Pin
        • Mount Type - Upper
          Mounting Plate
        • Prop 65 - Short Label
          WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov
        • Recommended Additional Part
          191009 - ICON LONG 2.5 COIL WRAP W/LOGO (14.5-15.5)
        • Recommended Additional Part
          198000 - 2 PIN COILOVER SPANNER WRENCH KIT
        • Recommended Additional Part
          198001 - BILLET SPANNER WRENCH KIT
        • Recommended Additional Part
          252001 - 2.5 Fixed Spanner Wrench
        • Recommended Additional Part
          252002 - Universal Spanner Wrench (2.0/2.5/3.0)
        • Recommended Additional Part
          252003 - Seal Install Tool 2.5/3.0
        • Recommended Additional Part
          252004 - Economy Needle Charging Tool
        • Recommended Additional Part
          252010 - 2.5 Ifp Rebuild Kit
        • Recommended Additional Part
          254100G - 1.0 Gallon Icon Performance Shock Oil
        • Recommended Additional Part
          611019 - Coilover Hardware Kit Pair
        • Recommended Aftermarket Tires
          33.0 in. X 11.5 in. (Larger Tires may Fit but Fender Trimming and Modifications will be Required)
        • Recommended Aftermarket Wheels
          ICON Alloys - 17x8.5" w/ 5.00” Backspace / 6mm Offset
        • Recommended Aftermarket Wheels
          ICON Alloys - 18x9" w/ 5.25" Backspace / 6mm Offset
        • Recommended Aftermarket Wheels
          ICON Alloys - 20x9" w/ 5.625" Backspace / 16mm Offset
        • Remote Reservoir
          No
        • Shaft Diameter
          0.875 in.
        • Shock Absorber Body End Measuring Point
          Top of Upper Mount Plate
        • Shock Absorber Rod End Measuring Point
          Flat on Bar Pin
        • Spring Color
          Black
        • Spring Material
          Steel
