ICON 2009-2013 Ford F-150 4WD, 1.75-2.63” Lift, Front, V.S. 2.5 Series Coilover Kit, Remote Reservoir
        ICON Vehicle Dynamics

        ICON 2009-2013 Ford F-150 4WD, 1.75-2.63” Lift, Front, V.S. 2.5 Series Coilover Kit, Remote Reservoir

        Part Number:91800
        ICON Vehicle Dynamics V.S. Series 2.5” remote reservoir coilover shocks are an incredible upgrade for the front end of the 2009-2013 Ford F150 4WD truck. ICON’s Vehicle-specific valving provides a sport tuned feel on and off-road while offering 1.75-3” of lift height adjustability for use of larger, more aggressive wheel and tire combinations. The larger 2.5” shock body and increased piston area over stock components provides improved damping ability and outstanding ride characteristics across varying types of terrain. Remote reservoirs ensure optimum performance by increasing the duration of consistent damping regardless of situation, keeping the shocks at a cooler operating temperature during heavy use. When paired with ICON rear 2.0 Aluminum Series or 2.5 Series shocks, vehicle control will be balanced front to rear resulting in the best overall driving experience for your Ford F150 4WD.
        • Increased wheel travel and ride quality over stock
        • Vehicle specific tuned for superior shock damping and control
        • External reservoirs to attain cooler operating temperatures during extended offroad use
        • Adjustable 1.75-3" lift height
        • ICON engineered Eibach Springs
        • 6061 Aircraft grade aluminum CNC machined components
        • Corrosion resistant CAD plated shock body with 7/8" diameter shaft
        • FK rod end bearings for extended longevity and minimal deflection
        • 100% Bolt-on - cutting or welding necessary for installation
        Retail price
        • $2,025.61
        Features
        • SKU
          91800
        • Brand
          ICON Vehicle Dynamics
        • AAP_UDA_12
          EA
        • AAP_UDA_22
          1
        • AAP_UDA_4
          55
        • Active or Passive Suspension
          Passive
        • Add-On Part
          97720P - 09-24 F150 2/4WD 04-08 F150 4WD REAR 2.5 VS PB PAIR
        • Add-On Part
          98500DJ - 04-20 F150 TUBULAR UCA DJ KIT
        • Add-On Part
          98505DJ - 09-20 F150/14-20 EXPEDITION BILLET UCA DJ KIT
        • Adjustable
          No
        • Adjustable Compression
          No
        • Adjustable Damping
          No
        • Adjustable Height
          Yes
        • Adjustable Rebound
          No
        • Body Diameter
          2.5 in.
        • California Prop 65 Warning
          Yes
        • Cylinder Color
          Silver
        • Cylinder Finish
          Cadmium Plated
        • Cylinder Material
          Steel
        • Damping Type
          Oil
        • Dust Shield Included
          No
        • Fitment Note
          Does fit OEM Wheels and Tires
        • Gas Charged
          Yes
        • Grade Type
          Performance
        • Housing Material
          Steel
        • Includes Boot
          No
        • Internal Construction Type
          Single Tube
        • Material
          Aluminum
        • Maximum Lift
          2.63 in.
        • Minimum Lift
          1.75
        • Mount Type - Lower
          Eyelet
        • Mount Type - Upper
          Mounting Plate
        • Prop 65 - Short Label
          WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov
        • Recommended Additional Part
          191009 - ICON LONG 2.5 COIL WRAP W/LOGO (14.5-15.5)
        • Recommended Additional Part
          191016 - 7.5 in. Finned Resi Upgrade Kit
        • Recommended Additional Part
          198000 - 2 PIN COILOVER SPANNER WRENCH KIT
        • Recommended Additional Part
          198001 - BILLET SPANNER WRENCH KIT
        • Recommended Additional Part
          252001 - 2.5 Fixed Spanner Wrench
        • Recommended Additional Part
          252002 - Universal Spanner Wrench (2.0/2.5/3.0)
        • Recommended Additional Part
          252003 - Seal Install Tool 2.5/3.0
        • Recommended Additional Part
          252011 - 2.5 Piggyback/remote Resi/bypass Rebuild Kit
        • Recommended Additional Part
          252012 - -4 TO -10 HOSE SHIELD KIT
        • Recommended Additional Part
          254100G - 1.0 Gallon Icon Performance Shock Oil
        • Recommended Additional Part
          611019 - Coilover Hardware Kit Pair
        • Recommended Aftermarket Tires
          33.0 in. X 11.5 in. (Larger Tires may Fit but Fender Trimming and Modifications will be Required)
        • Recommended Aftermarket Wheels
          ICON Alloys - 17x8.5" w/ 5.00” Backspace / 6mm Offset
        • Recommended Aftermarket Wheels
          ICON Alloys - 18x9" w/ 5.25" Backspace / 6mm Offset
        • Recommended Aftermarket Wheels
          ICON Alloys - 20x9" w/ 5.625" Backspace / 16mm Offset
        • Remote Reservoir
          Yes
        • Reservoir Style
          Remote
        • Self-Leveling
          No
        • Shaft Diameter
          0.875 in.
        • Shock Absorber Body End Measuring Point
          Top of Upper Mount Plate
        • Shock Absorber Rod End Measuring Point
          Center of Eyelet
        • Spring Color
          Black
        • Spring Material
          Steel
        • Spring Rate Type
          Linear
        • Valving Type
          Digressive
