07-21 TUNDRA 1-3" STAGE 2 SUSPENSION SYSTEM
ICON Vehicle Dynamics

07-21 TUNDRA 1-3" STAGE 2 SUSPENSION SYSTEM

Part Number:K53022
ICON Vehicle Dynamics Toyota Tundra Stage 2 suspension systems are designed with maximum performance and the serious driver in mind. ICON engineers’ primary focus is to increase wheel travel and damping ability, which translates into outstanding vehicle control and ride quality both on and off-road. The Stage 2 system includes vehicle-specific tuned 2.5” coilover shocks featuring an internal reservoir for exceptional cooling properties. These coilovers are also height adjustable from 1-3” of lift allowing the use of larger, more aggressive wheel and tire combinations. ICON 2.0 VS Aluminum Series monotube rear shocks utilize a vehicle-specific valving and then when combined with ICON's expansion pack give you the performance of the truck from front to rear. The ICON Vehicle Dynamics 2007-2021 Toyota Tundra Stage 2 suspension system is an excellent choice for those drivers looking to enhance the capabilities of their pickup on the road as well as in the dirt.
  • Increased wheel travel and ride quality over stock with no change in towing capacity
  • Vehicle specific tuned front and rear shocks for superior shock damping and control
  • Adjustable coilovers from 1-3" of lift height
  • 6061 Aircraft grade aluminum CNC machined components
  • Corrosion resistant CAD plated coilover shock body with 7/8" shaft
  • FK rod end bearings for extended longevity and minimal deflection
  • 2.0 VS Aluminum Series with 5/8" polished nitro steel shaft
  • 1.5" lift Rear Exspansion pack for better ride quaility
  • 100% Bolt-on system - no drilling, cutting, or welding necessary for install
Retail price
  • $2,416.04
Features
  • SKU
    K53022
  • Brand
    ICON Vehicle Dynamics
  • Fitment Note
    Does fit OEM Wheels and Tires
  • Grade Type
    Performance
  • Includes Bushings
    Yes
  • Includes Mounting Hardware
    Yes
  • Includes Shocks
    Yes
  • Leaf Spring Leaf Quantity
    3
  • Maximum Lift
    3.5 in.
  • Prop 65 - Short Label
    WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov
  • Recommended Additional Part
    198000 - 2 PIN COILOVER SPANNER WRENCH KIT
  • Recommended Additional Part
    198001 - BILLET SPANNER WRENCH KIT
  • Recommended Aftermarket Tires
    35.0 in. X 12.5 in. (Larger Tires may Fit but Fender Trimming and Modifications will be Required.)
  • Spring Material
    Steel
