Bilstein Shock Absorbers
Bilstein

Bilstein Shock Absorbers

Part Number:26-253282
Discontinued
Bilstein MDS (Modular Damping System) dampers are a premium motorsports product designed for professional road racing. The 2-way independent compression and rebound adjustment system provides 100 different setting variations for the ultimate in handling performance. The Easy Clip System (ECS) spring retainer system allows for rapid spring changes for easy at the track suspension tuning. MDS dampers are ideal for full-race car applications that demand exceptional versatility and fine tuning for track conditions. Bilstein MDS dampers provide proven performance and have taken many race cars to victory at races such as the 24 Hours of Le Mans and the 24 Hours of Nürburgring.
  • 2-way independent rebound and compression adjustment system
  • In-line damping adjustment requires no external reservoir
  • Easy Clip System (ECS) spring retainer maintains position in zero preload spring applications and allows rapid changes
Retail price
  • $2,250.00
Features
  • SKU
    26-253282
  • Brand
    Bilstein
  • Adjustable Damping
    Yes
  • Body Design
    Threaded Body
  • Body Inside Diameter
    46.0 mm
  • Body Material
    Aluminum
  • Coilover Type
    Coilover
  • Collapsed Length
    12.78 in.
  • Collapsed Length
    324.6 mm
  • Color
    Natural
  • Compression at 0.52 m/s
    Adjustable
  • Damping Type
    Double Adjustable - Compression and Rebound
  • Extended Length
    14.96 in.
  • Extended Length
    380.0 mm
  • Finish
    Anodized
  • Includes Boot
    No
  • Includes Spring Seat
    Yes
  • Internal Design
    Monotube
  • Lower Mount Type
    Clevis
  • Piston Type
    Linear
  • Position
    Rear
  • Rebound @0.52m/s
    Adjustable
  • Series
    MDS
  • Upper Mount Type
    15.0 mm Heim
