ICON 2022-2023 Toyota Land Cruiser 300 Series, 0-2” Lift, Rear, 2.5 VS Remote Reservoir CDCV Shocks, Pair
ICON Vehicle Dynamics

ICON 2022-2023 Toyota Land Cruiser 300 Series, 0-2” Lift, Rear, 2.5 VS Remote Reservoir CDCV Shocks, Pair

Part Number:57827CP
ICON Vehicle Specific (V.S.) 2.5 Aluminum Series CDCV shocks are designed and built to give your vehicle outstanding performance off-road and a smooth ride on the street. These shocks are configured specifically for each application in both length and damping tune. Like all ICON'S Shock Absorbers, V.S. 2.5 Aluminum Series shocks are 100% rebuildable and 100% revalveable. For piggyback and specific remote reservoir applications, ICON'S unique use of a 6061 billet aluminum manifold a few inches below the top cap of the shock creates an internal Bump Zone that when used creates an additional 20% of damping force. This additional force helps prevent harsh bottom outs and controls the suspension when compressing at high velocity. The ICON CDC Valve is an externally adjustable valve that restricts oil flow into the reservoir which creates 10 levels of compression damping force ranges.
  • Premium grade 5WT shock oil for consistent suspension damping along a wide temperature range
  • Nitrogen charged monotube design with remote reservoir
  • 100% Rebuildable
  • 100% Revalveable
  • One-piece impact extruded aluminum cylinders offer excellent corrosion resistance and consistent finish
  • Remote reservoir design improves heat dissipation to reduce shock fade during prolonged use
  • 6061 aircraft grade aluminum CNC machined components
  • ICON’s internal “Bump Zone” increases damping by 20% to provide more control as the shock approaches full compression
  • ICON's CDC Valve technology allows for 10 levels of high-resolution compression adjustability with the turn of a knob
  • PTFE lined spherical bearings and application specific mounting hardware
  • 7/8” diameter induction hardened, chrome plated shock shaft
  • One piece digressive piston design with vehicle specific valving for unsurpassed performance and ride quality on and off-road
Retail price
  • $1,625.13
Features
  • SKU
    57827CP
  • Brand
    ICON Vehicle Dynamics
  • Adjustable Damping
    Yes
  • Bore Diameter
    57.15.0 mm
  • Damping Adjustment Type
    Manual
  • Damping Type
    Oil
  • External Reservoir
    Yes
  • Gas Charged
    Yes
  • Grade Type
    Performance
  • Includes Boot
    No
  • Includes Mounting Hardware
    Yes
  • Lower Mount Type
    Eyelet
  • Mount Type - Upper
    Stem
  • Prop 65 - Short Label
    WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov
  • Recommended Additional Part
    191016 - 7.5 in. Finned Reservoir Upgrade Kit
  • Recommended Additional Part
    252001 - 2.5 Fixed Spanner Wrench
  • Recommended Additional Part
    252002 - Universal Spanner Wrench (2.0/2.5/3.0)
  • Recommended Additional Part
    252003 - Seal Install Tool 2.5/3.0
  • Recommended Additional Part
    252008 - 2.5 X 13 SHOCK BOOT BLACK (PAIR)
  • Recommended Additional Part
    252011 - 2.5 Piggyback/remote Reservoir/bypass Rebuild Kit
  • Recommended Additional Part
    252012 - -4 TO -10 HOSE SHIELD KIT
  • Recommended Additional Part
    254100G - 1.0 Gallon Icon Performance Shock Oil
  • Recommended Additional Part
    257340 - 0.875 in. Shaft 14.25 Overall Length, 10.0 Travel
  • Recommended Additional Part
    611007 - 0.563 in. Medium Duty Stem Bushing Kit
  • Shaft Diameter
    0.875 in.
  • Shock Absorber Body End Measuring Point
    Shoulder of Stem
  • Shock Absorber Rod End Measuring Point
    Center of Eyelet
  • Tube Outside Diameter
    2.5 in.
